Fabricating bio-inspired high impact resistance carbon nanotube network films for multi-protection under an extreme environment
Researchers found that the bio-inspired carbon nanotube network exhibits significantly higher toughness and impact resistance compared to conventional protective materials like steel and Kevlar.
The fabrication of light-weight, highly impact-resistant, and energy-absorbent materials is urgently demanded in many facets of the society from body armor to aerospace engineering, especially under an extreme environment. Carbon nanotubes (CNTs), one of the strongest and toughest materials ever found, also have good conductivity, chemical stability, and thermal stability, etc, making them a competitive candidate as building blocks to help achieve the above goal.
Event Tip: Fundamentals of Functional Coatings
Dive into the world of functional coatings designed to offer specialized properties such as anti-fouling, anti-ice, easy-to-clean, and drag reduction. This tutorial will cover fundamental principles, materials selection, surface modification techniques, and case studies across different applications. Join us online on 03 Oct 2024 for the EC Short Course “Fundamentals of Functional Coatings” and explore how these coatings are transforming industries worldwide.
In the work, a kind of CNT network was prepared by using chlorosulfonic acid (CSA) to release the internal stress of super-aligned carbon nanotube films (SA-CNTF) and dendritic polyamide amine (PAMAM) to further introduce multiple hydrogen bonds and interlocking structures. The fabricated bioinspired carbon nanotube network films (PAMAM@C-CNTF) have a high toughness of 45.97 MJ/m3, showing an increase of 420% compared to neat SA-CNTF. More importantly, the anti-impact performance of the films (e.g., with a maximum specific energy absorption of 1.40 MJ/kg under 80–100 m/s projectile impact) is superior to that of conventional protective materials from steel and Kevlar fiber, and also exceeds that of any other reported carbon-based materials. The hierarchical energy dissipation mechanism was further revealed through experiment and simulation. Additional functions including intelligent heating/anti-icing, ultraviolet protection, as well as electromagnetic interference shielding properties make these network films have great potential in practical multi-protection applications, especially under an extreme environment.
Nano Research, Volume 17, pages 7793–7802, (2024)
